Description
Features:
- 7-inch color touch control screen, programmable imported PLC control system, easy to operate;
- Parameters can be set (such as weight, bag length, packaging target quantity, reset, etc.);
- Intelligent temperature controller control, firm sealing, good sealing performance, exquisite and beautiful packaging;
- Automatically complete all tasks such as material handling, weighing, filling, bag making, sealing, and cutting;
- Independent research and development of material handling mechanism and weighing system, with fast operation speed and high accuracy;
- It can be equipped with a coding machine, a labeling machine, a scale for repeated inspection, a finished product conveyor, and a manipulator.
Parameters：
| Model: | DXD-320T4 |
| Bag Size: | W:30-180MM, L:30-180mm |
| Packing material: | OPP/PE,PAC/PP,PA/PE,PET/CPP ETC Composite Membrane |
| Packing Speed: | 10~60bags/min(the speed depends on type of products and quantity) |
| Voltage: | AC220V,50/60HZ |
| Power: | 2.6KW |
| Pressure： | 0.6-0.8Mpa |
| Sealing Style: | 3 sides,4 sides,back sealing |
Application:
Suitable for automatic counting and packaging machine for screws, nails, bolts, nuts, gaskets, bearings, glass parts, plastic parts, furniture accessories, toy accessories, blind nuts, gaskets, hardware and plastic parts, etc.
Packing Machine Video:
